BIGTREETECH Manta M5P V1.0 Control Board 32Bit Support 5 Axis TMC2209 TMC5160 Drivers Compatible with CB1/CB2/CM4 HDMI5 PITFT50 TFT35 SPI Display to Running Klipper for Ender 3/Voron V0 FDM 3D Printer

BIGTREETECH Manta M5P Control board Product Introduction:BIGTREETECH Manta M5P is a 32-bit motherboard developed by the 3D printing team of Shenzhen Big Tree Technology Co.,Ltd. for Klipper running.It can run Klipper with a core board,which greatly eliminates the mass wiring between the motherboard and Raspberry-Pi ,and also greatly saves space in the chassis.The BTB header sare designed on Manta M5P, so that customers can choose to use CM4 or other solutions, thus solving the insane shortage of Raspberry-Pi CM4.Main Features1. 32bit 64MHz ARM Cortex-M0+ series STM32G0B1RET6 MCU.2. The thermistor circuit is protected to prevent MCU damage from shorted heated bed and heater cartridge connections.3. The CNC fan's voltage is selectable in 24V, 12V, and 5V, no more need for external stepdown thus preventing board damage from user error.4. Thermistor connection supports pull-up resistance value setting using jumpers, no more extra module needed for PT1000.5. MCU firmware can be upgraded via an SD card, or use DFU via Klipper's make flash command.6. BTB connectors are adopted between the motherboard and core board, allowing the choice of other core board solutions in addition to CM4.7. Integrated SPI and UART mode of TMC driver and DIAG pin, easily configurable with jumpers.8. Support filament runout sensor, BLTouch, RGB, etc.9. Replaceable fuse for easy maintenance.10. Onboard proximity switch port, support NPN and PNP type selection, (24V, 12V, 5V) voltage selection.11. Onboard SPI interface for connecting acceleration sensor to enable Klipper's input shaping.12. The new E-FUSE fuse is equipped, which can respond quickly, enhance self-protection ability, and greatly reduce the motherboard burnout caused by short circuits or ignition.

• Main Control Chip Upgraded: BIGTREETECH Manta M5P control board adopts 32bit ARMCortex-M0STM32G0B1RET6 chip, frequency of 64MHz, it can installation of the BIGTREETECH CB2/CB1/eMMc/Raspberry-Pi CM4 to run the Linux systyem, running Klipper, when without CB1 or CM4, can Running Marlin.
• Abundant Connectivity: BTT Manta M5P support USB2.0*3, LAN,DSC,CSI, SPI, HDMI0 and HDMI1 display (PITFT50 V2.1, HDMI5 V1.1, TFT35 SPI), SOC-Card, MCU-Card, Onboard CAN, Probe,RGB*2, SPI,EXP1+EXP2, MIN1-MIN4, 40Pin-GPIO (about CANBUS,Can be directly connected to EBB using Klipper's USB to CAN bus bridge function).
• Rich Expansion Ports: Support filament runout detection sensor, BLtouch, BIQU Microprobe, RGB Lights, automatic shutdown module, Onboard proximity switch and SPI(ADXL345) port ,support NPN and PNP type selection,(24V,12V,5V)voltage selection, for users use Klipper firmware to connect external acceleration sensor for acceleration compensation.
• Easy operation: Thermistor can select the value of pull-up resistor through jumper to support PT1000 without external module Convenient for user to DIY and the MCU firmware can be upgraded through SD card, or updated through DFU through Klipper's makeflash command.
• Power chip upgraded: The Power Chip adopts TPS5450-5A, the 5A output perfectly matches the power supply need of Raspberry-Pi, integrated SPI and UART mode of TMC driver and DIAG pin,easily configur able with jumpers, please follow the Github Manual instructions for details.
• After-sales service: The firmware update and installation instructions for Manta M5P have been uploaded to bigtreetech Github. If you encounter any problems during use, please let us know as soon as possible and we will give you a satisfactory solution.
